Filling and wrapping machine for miniportions of butter Benhil 8304 - 8534

Benhil 8304 foil wrapping machine which can be used for packing products butter, lard, margarine, tvorog or cottage cheese into aluminium foil. The format on the machine is 10 - 25 gram, 40 x 30 x ± 10 - 25 mm, bottom folding principle. The machine is currently set on 10 gram. Packaging material: aluminium foil with photocell mark. Widht of the foil: 85 mm. The photocell line distance is 80 mm. The butter is feed with a hopper with agitator screw inside, mechanically drive from out of the main machine (tooth wheels and axles). The machine is equiped with a photocell on the paper infeed, to control the exact position of the print on the foil (correct by brake system). If there is no foil at the first folding station, the machine will stop. Mechanical belt driven outfeed conveyor of ± 1.000 mm, mounted 90° on the machine to the semi automatic case packer, Benhil 8534. The Benhil 8304 machine is also equipped with a semi automatic case packer, Benhil 8534 for stacking the format and preparing the layers inside the carton box. Current stacking format: 5x5x4 = 100 portions per carton box. Current box dimensions: 205 x 155 x ± 40 mm. Manual adding and removal of the carton box by the operator. Machine reconditioned / modified in 1993 by Benhil / Benz & Hilgers by Auftrag A93-263.
